40-Position ZIF Breakout Board from Crystalfontz

Product

Home » Products » Accessories » Carrier Boards


      40-Position ZIF Breakout Board
      Part Number: CFABB-CS050Z40G-B0
    This ZIF breakout board includes our 40-pin 0.5-millimeter pitch ZIF connector broken out to 0.1" through holes. Grab this breakout board for quick prototyping with displays that have 40 pins or fewer at a 0.5 mm pitch.

Don't forget to add a few of our dual-row headers to populate the through holes.

This breakout board was specifically designed to connect to our multi-use ZIF breakout board. Solder this to the empty through holes on the multi-use board to add any size ZIF connector so you can have a perfect fit.

Part Number:

CFA- Crystalfontz America

BB- Breakout Board

CS050Z40G-B0- includes this connector

Connector Part Number:

CS- Crystalfontz Connector

050- 0.5mm pitch

Z - Top and Bottom Connectors

40- 40 pins

G - Gold

B0 - Family and revision
 square_foot Physical Characteristics
Physical Characteristics

        Weight
            4.3g
Pin Count
            40

 download Files and Downloads
picture_as_pdf Other Document - CFA10102 Integration Guide
picture_as_pdf Other Document - Getting Started Guide
 assured_workload Compliance Documents
 picture_as_pdf Declaration of Conformity RoHS2
 picture_as_pdf Declaration of Conformity REACH

Need a written quote? Add to cart, then enter your email address in the "request a quote" box.
 Quantity:

Price:

            Quantity
            Unit Price

            1
            $6.43

59 Units In-Stock & Ready To Ship
 Pricing is subject to change.
* Contact us about potential lead times.
Other components worth considering

						40 Position, 0.50mm Pitch, Gold, FCC FPC ZIF connector
Add 5 ZIF Connectors? $1.45 ea.

						72 Pin Header
Need header pins? $0.66 ea.

						Multi-use ZIF Breakout Board
Need a breakout board? $22.34 ea.

						6-inch Female to Female Jumper Wires
Add jumper wires? $3.38 ea.

Quantity	Unit Price
1	$6.43
